Most Popular Product
|
MEE Wastewater Evaporators
100000 - 10000000 INR/Piece
Product Details:
- Efficiency (%) Above 98%
- Usage & Applications Zero Liquid Discharge, Effluent Treatment, Wastewater Recycling
- Feature Corrosion Resistant, Modular Design
- Noise Level Less than 80 dB
- Flow Rate Variable, up to 100 KLPD
- Ph Level Neutral (6.5-7.5)
- Water Out Conductivity Less than 10 S/cm
- Click to View more
X
MEE Wastewater Evaporators Price And Quantity
- 100000 - 10000000 INR/Piece
- 1 Piece
- PLC based automatic controls
- Ambient to 40°C
- CIP (Clean-in-Place)
- Up to 3 kg/cm²
- Manual or automatic
- On-site installation and commissioning
- Internal and external epoxy coating
- Efficient Mist Eliminators
- 2 to 7 effects as per design
- Falling film / Forced circulation
- Up to 110°C
MEE Wastewater Evaporators Product Specifications
- Less than 80 dB
- Variable, up to 100 KLPD
- 415 V
- Integrated Pre & Post Filtration
- Corrosion Resistant, Modular Design
- Skid Mounted
- High Purity Water Output
- Zero Liquid Discharge, Effluent Treatment, Wastewater Recycling
- 500 LPD - 100 KLPD
- Above 98%
- Automatic
- Mechanical
- Centrifugal/Multi-stage
- As per capacity, typically 1.0-2.0 kWh per kg evaporation
- Up to 95%
- Wastewater Evaporator
- Electric
- Up to 80,000 S/cm
- Stainless Steel (SS304/SS316)
- Industrial Wastewater
- Multi Effect Evaporation
- 50 Hz
- Customizable as per requirement
- Neutral (6.5-7.5)
- Less than 10 S/cm
- PLC based automatic controls
- Ambient to 40°C
- CIP (Clean-in-Place)
- Up to 3 kg/cm²
- Manual or automatic
- On-site installation and commissioning
- Internal and external epoxy coating
- Efficient Mist Eliminators
- 2 to 7 effects as per design
- Falling film / Forced circulation
- Up to 110°C
MEE Wastewater Evaporators Trade Information
- 10 Piece Per Month
- 15-30 Days
Product Description
Industrial wastewater is treated using MEE Wastewater Evaporators, which evaporate the water content and create solid residues that can be disposed of safely. A series of vessels that operate at progressively lower pressures and temperatures are what define MEE evaporators. The vapor from one effect is used to heat the next. MEE Wastewater Evaporators are frequently used in sectors like chemical processing, food and beverage production, and pharmaceuticals where solution concentration or separation is necessary. They are renowned for using energy with great efficiency and having lower operating costs. They are capable of zero liquid discharge, which means that all wastewater is evaporated and there is no liquid discharge.
Specification
|
Installation Service |
Yes |
|
Brand/make |
Kings Eva |
|
Min Capacity |
100 lit/hr |
|
Max Capacity |
2000 lit/hr |
|
Atm Temperature |
30-40 degree C |
|
Power |
Max 75 hp |
|
MOC |
MS, SS |
Precision Controls for Reliable Operation
Our MEE Wastewater Evaporators incorporate PLC-based automatic control systems, ensuring precise and reliable performance. The user-friendly interface enables tailored adjustments for various feed conditions and supports both manual and automatic concentrate removal. This automation minimizes operator involvement and facilitates seamless integration into existing treatment frameworks.
Robust and Efficient Design
Designed with industrial-grade stainless steel (SS304/SS316) and internal/external epoxy coatings, these evaporators are highly corrosion-resistant. Efficient mist eliminators and modular design guarantee minimal energy consumption (1.02.0 kWh/kg evaporation) and maximum uptime. The heat exchanger optionsfalling film and forced circulationensure effective heat transfer across varying throughput demands.
Comprehensive Support and Service
Our experienced team provides on-site installation, commissioning, and ongoing support services. With customizable capacities and modular, skid-mounted design, we ensure swift deployment and hassle-free scaling. Exported and supplied across India, our solutions are designed to surpass efficiency standards, achieving above 98% performance for zero liquid discharge and water recycling.
FAQs of MEE Wastewater Evaporators:
Q: How does the MEE Wastewater Evaporator achieve high water recovery rates?
A: The MEE system utilizes 2 to 7 effects in series, optimizing vapor reuse and minimizing energy consumption. This multi-effect design, combined with efficient mist elimination and advanced heat exchangers, enables up to 95% water recovery from industrial wastewater streams.Q: What type of maintenance is required for these evaporators, and how is cleaning managed?
A: Maintenance is straightforward due to the Clean-In-Place (CIP) system, which allows for automated internal cleaning without dismantling equipment. The corrosion-resistant SS304/SS316 material and epoxy coatings further minimize regular maintenance needs.Q: When should the evaporator be used in an industrial water treatment process?
A: Deploy the MEE Wastewater Evaporator when aiming for zero liquid discharge, maximum water recycling, or when handling high-conductivity wastewater (up to 80,000 S/cm). Its ideal after primary treatments for achieving high purity water output and reducing environmental impact.Q: Where can these evaporators be installed and what is the typical installation method?
A: MEE Wastewater Evaporators are suitable for a wide range of industrial sites and are supplied as modular, skid-mounted units, ensuring flexible placement and fast on-site installation. Our team handles installation and commissioning across India and for export projects.Q: What are the energy requirements and operational efficiency of the system?
A: Energy consumption typically ranges from 1.0 to 2.0 kWh per kilogram of water evaporated, depending on capacity and operation. With above 98% operational efficiency, the system leverages PLC automatic controls and recycles vapor heat to minimize overall power use.Q: How does the evaporator ensure consistent water quality in the output?
A: Integrated pre- and post-filtration, along with efficient vapor separation and precision controls, ensure water output consistently meets high purity standards, with final conductivity less than 10 S/cm and pH levels in the neutral range (6.57.5).Q: What benefits do users gain from using MEE Wastewater Evaporators?
A: Users benefit from reduced liquid waste volumes, regulatory compliance via zero liquid discharge, significant water recycling savings, minimal downtime due to automated cleaning, corrosion-resistant construction for longevity, and customizable solutions tailored to specific process needs.Tell us about your requirement
